Hinvert 3KW 24V MPPT Solar Off-Grid Hybrid Inverter with Built-in WiFi – Overview
The Hinvert HMK-Plus 3KW 24V PV-4000W Single Phase Off-Grid Solar Inverter is a powerful and efficient hybrid solution designed for medium-scale residential and commercial solar systems. Equipped with advanced MPPT technology, pure sine wave output, and built-in WiFi monitoring, this inverter ensures maximum solar energy harvesting and stable power delivery. Its robust design supports higher loads, making it ideal for continuous and reliable off-grid energy systems.
Key Benefits
- Provides stable 3000W continuous output with high surge capacity for heavy appliances.
- Advanced MPPT charge controller supports up to 4000W solar input for optimal efficiency.
- Pure sine wave output ensures safe operation of sensitive electronics and equipment.
- Built-in WiFi monitoring allows real-time performance tracking and remote management.
- Supports operation with or without battery for flexible solar system configurations.
- Wide MPPT voltage range (60V–430VDC) supports various solar panel setups.
- High efficiency up to 98% ensures minimal power loss and better energy utilization.
- Multiple communication interfaces (USB, RS232, RS485, WiFi) for system integration.
For a complete solar solution, pair this inverter with high-quality solar panels and a reliable battery bank to ensure efficient energy generation, storage, and uninterrupted power supply for both day and night usage.
Technical Specifications
| Parameter | Value |
|---|---|
| Brand | Hinvert |
| Model | HMK-PLUS 3KW |
| Product Type | MPPT Off-Grid Hybrid Solar Inverter |
| Rated Power | 3000W / 3000VA |
| Surge Power | 6000VA |
| DC Input | 24VDC, 120A |
| Battery Voltage | 24V DC |
| Floating Charge Voltage | 54VDC |
| Overcharge Protection | 66VDC |
| AC Input Voltage | 230VAC |
| AC Output | 230VAC, 50/60Hz, 11.0A, Single Phase |
| Frequency | 50Hz / 60Hz |
| Waveform | Pure Sine Wave |
| Max PV Power | 4000W |
| Nominal PV Voltage | 240VDC |
| Max Solar Voltage (VOC) | 450VDC |
| MPPT Voltage Range | 60V – 430VDC |
| Max PV Input Current | 27A |
| MPPT Charging Current | 80A |
| Default Charging Current | 30A |
| DC Output | 27VDC |
| Efficiency | Up to 98% |
| Communication Interface | USB / RS232 / RS485 / WiFi |
| WiFi Monitoring | Built-in |
| Works Without Battery | Yes |
| Sleeping Mode | Yes |
| Display | LCD Display |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -15°C to 60°C |
| Dimensions (H*W*D) | 380 x 310 x 128 mm |
| Weight | 10 kg |
| Country of Origin | China |
| Certification | RoHS & CE |
| Warranty | 2 Years |
For manufacturer details, see the official page: Hinvert HMK-PLUS 3KW
